Series: W83 Series
Model No.: W83/45L1
Rated Current: 45A 250V~
Color: White
Size: 86X86 mm
Quality Assurance:10 years
Standard: British
Certificates: CB, CE, SASO
45A 250V Double Pole Switch with Neon features thin panel design while keeps the item durable with high quaity PC material. The integration of plate and metal frame makes the product solid and difficult to deform but it’s easy to install with convenient locking design.
Product Introduction of the 45A 250V Double Pole Switch with Neon - White
1. Features a simple and clean outlook because fixing hole is concealed by slim cover plate.
2. Selecting high polymer PC on shell frame to support such a slim profile which isonly 7mm, scratches-resistant, fire-resistant, discoloration-resistant, fading-resistant, very durable and easy for cleaning.
3. Supplied LED indicator design for guidance. Double pole switch offers you double safety.
4. Offers quick installation and easier disassembly.
5. Both Single pole switched socket and USB outlets are available.
6. Provides a full range of solutions for Industrial, commercial, hotels, residential and office building.
7. Well-trained & professional service team willanswer you within 24 hours with their 20-year exporting experience.
8. We offer multipayment terms: D/P, D/A, T/T, L/C and Cash etc. as we have solid financial strength with low asset-liability ratio.
9. As your excellent partner-ship in China, we can support you with transportation, booking shipment, interpreting etc.
Product Parameter (specification) of the 45A 250V Double Pole Switch with Neon - White
| Main | |
| Type | Light Switch |
| Series | W83 series |
| Brand Name | SOK |
| Model Number | W83/45L1 |
| Color | White |
| Material | PC, PP |
| Complementary | |
| Rated Voltage | 250V~ |
| Rated Current | 45A |
| Network Frequency | 50/60Hz |
| Number of Gangs | 1 Gang |
| Function | Double pole |
| Actuator | Rocker |
| Device Mounting | Flush/Surface mounted |
| Fixing type | Concealed screws |
| Fixing Mode | By screw M3.5 |
| Fixing Screws Material | Zinc-plated |
| Connections | Screw terminals(pillar terminal)M3.5*7.2mm |
| Contacts Material | Brass |
| Embedding Depth | 35 mm |
| Dimension | 86*86mm |
| Environment | |
| Ambient Air Temperature for Operation | -5~40℃ |
| Flame Retardancy | 850℃ |
| IP degree of protection | IP20 |
| Standards | BS EN 60669-1
SS 227 IEC 60669 |
| Application | Projects like Residential, Hotel, hospital, plaza, Industrial |
| Contractual Warranty & Tested Lifetime | |
| Tested Lifetime | At least 40,000 times |
| Warranty | 10 years |
| Packing | |
| Packing | 1 pcs/ plastic bag 150*120mm
10pcs/box 185*154*93mm 100pcs/carton 490*320*200mm |
| More Info. | |
| Payment term | T/T, L/C, D/P... |
| MOQ | 3000 pcs |
| Manufacture | Guangdong Jinli |
| Place of Origin | Guangdong, China |
| Certificate | SASO, CB, CE, Jinli factory Successfully certified with ISO9001 & ISO14001 quality system certificate |
Product Details of the 45A 250V Double Pole Switch with Neon - White
Product Quali
fication of the 45A 250V Double Pole Switch with Neon - White
Our company covers 300,000 square meters, and there are injection workshop, mold manufacturing workshop, coloring workshop, metal parts punching workshop, assembly workshop, warehouses, CNAS certified laboratory and office building.
BEAUTIFUL OFFICE BUILDING
MOLD WORKSHOP
INJECTION WORKSHOP
METAL PUNCHING WORKSHOP
PLASTIC COLORING WORKSHOP
ASSEMBLY WORKSHOP
ISO9001, ISO14001 & CNAS TEST LABORATORY CERTIFICATES
Deliver, Shipping and Serving of the 45A 250V Double Pole Switch with Neon - White
STANDARD POLY BAGS & BOXES & CARTONS
FAQ of the 45A 250V Double Pole Switch with Neon - White
Q: Can you do OEM for us?
A: Yes, we do OEM according to the customers’ package and quantity. We can print your brand on the packing or even on the product. Also, you can customize your own designs with us or provide us samples because we have injection workshop, mold workshop, and coloring workshop to meet your demands.
Q: What’s your price terms?
A: CNF, CIF, FOB SHUNDE, EXW, CFR depending on the clients’ requirement.
Q: How’s your guarantee policy?
A: We provide 10-year guarantee for general electric wiring device like two way switch, single pole switch, modular switches, door bell switch, German socket outlet, British outlets, cooker switch, different plug socket. And 2-year warranty for electronic products like USB outlets quick charge 3.1/2.1A, dimmer light switch, motion sensor light switch, Thermostat etc.
Q: What certification have you obtained?
A:We have obtained CE, CB, ROHS, TUV, VDE, SASO, GCC, Inmetro for products, and our company has ISO9001, ISO14001, OHSAS18000 certification.
