Series: W83 Series
Model No.: W83/10U
Rated Current: 10A 250V~
Color: White
Warranty: 10 years
Standard: British
Certificates: CB, CE, SASO
Switch & Power Socket Terminal Clamping Force Test Video:
W83 Series integrates with aesthetics and classic elements in its decorative design, selecting high quality PC material which has the function of flame resistance, discoloration resistance and impact resistance.
Product Introduction of the 10A 250V 2 Gang 2 Pin Socket Outlets - White
1. Features smooth edges and slim front plate. Glossy switch button can be customizedto other PC color or painting finish.
2. Offers no visible fixing screws design, applying high polymer PC material to support such a slim profile which is durable, fire-resistant, fading-resistant, discoloration-resistant and scratches-resistant.
3. Earthed Metal Frame and Screws and Child-Proof Shuttered Outlets provide you a safe environment.
4. Thanks to the convenient locking of cover plate and chassis and large wiring space, this item features time-saving wiring and installation.
5. Ideal for redecoratedand other applications where mounting-box space is limited.
6. Communication socket and 2 way switch available.
7. Provides a wide range of solutions for commercial building, hotels and residential spaces.
8. SOKprovides 10-year worry-free warranty for all types of non-electronic items like modular switches, power switch, wall socket, cooker switch...Our friendly and professional sales and efficient technical teams are ready to support your requirements.
9. Product reliability tests all can be done in our company as we own a CNAS certified laboratory, mold manufacturing workshop and 80 engineers in R& D technical team.
10. 108 injection machines, 20 high-speed punch machines, 100 assembly lines, an excellent team for quality control and production capacity over 10 million pieces a month, all this favourable conditions provide fast delivery.
Product Parameter (specification) of the 10A 250V 1 Gang 2 Pin Socket Outlet - White
| Main | |
| Type | 2 Pin socket outlet |
| Series | W83 series |
| Brand Name | SOK |
| Model Number | W83/10US |
| Color | White or customized |
| Material | PC, PP, Copper |
| Complementary | |
| Rated Voltage | 250V~ |
| Rated Current | 10A |
| Network Frequency | 50/60Hz |
| Number of Gangs | 2 Gangs |
| Function | With Child-proof shutter |
| Device Mounting | Flush wall mounted |
| Fixing type | Concealed screws |
| Fixing Mode | By screw M3.5 |
| Fixing Screws Material | Zinc-plated |
| Connections | Screw terminals(pillar terminal)M3*6.5mm |
| Contacts Material | Brass |
| Embedding Depth | 20 mm |
| Dimension | 86*86mm |
| Environment | |
| Ambient Air Temperature for Operation | -5~40℃ |
| Flame Retardancy | 850℃ |
| IP degree of protection | IP20 |
| Standards | British |
| Application | House, Commercial, Industrial, Hospital, Residential using |
| Contractual Warranty | |
| Warranty | 10 years |
| Packing | |
| Packing | 1 pcs/ plastic bag 150*120mm
10pcs/box 185*154*93mm 100pcs/carton 490*320*200mm |
| More Info. | |
| Payment term | T/T, L/C, D/P... |
| MOQ | 3000 pcs |
| Manufacture | Guangdong Jinli |
| Place of Origin | Guangdong, China |
| Certificate | Jinli factory Successfully certified with ISO9001 & ISO14001 quality system certificate |
Product Details of the 10A 250V 2 Gang 2 Pin Socket Outlets - White
Product Qualification of the 10A 250V 2 Gang 2 Pin Socket Outlets - White
With rich ODM & OEM experience and 35-year history in producing light switches and socket outlets, SOK can do more than that to win your satisfaction.
MOLD WORKSHOP & INJECTION WORKSHOP
BEAUTIFUL OFFICE BUILDING
Jinli factory Successfully certified with ISO9001 & ISO14001 quality system certificate & CNAS TEST LAB
Concentrating on Wall switch and socket outlet manufacturing for 35 years, SOK has developed 30 series of wide range products to meet the requirement of BS standard, European standard and Italy standard. VDE, TUV, CE, CB, ROHS, GCC, SASO, Inmetro Certificates are available.
Deliver, Shipping and Serving of the 10A 250V 2 Gang 2 Pin Socket Outlets - White
STANDARD PACKING
FAQ of the 10A 250V 2 Gang 2 Pin Socket Outlets - White
Q: What’s your payment terms?
A: Our payment terms is D/P, T/T, L/C at sight 30 days/60 days, Cash, Western Union. 30% as deposit and 70% as balance should be paid before shipment.
Q: Can you OEM for us?
A: Yes, we can OEM according to the client’s quantity and package. We can make your brand on the package or even on the product cover plate or housing or chassis. Also, you can customize your own designs with us.
Q: Can you send free samples?
A: Yes, we would like to arrange free samples for you. Please don’t hesitate to share the one you’re interested in by E-mail: export01@jinli.com.
Q: What’s your delivery time?
A: Normally manufacturing cycle is 30-45 days. Our efficient service team could arrange shipment for you after finishing production.
